Descripción
3 Way Active Crossover
Features
• PMW Power Supply
• 3-Way Active Crossover w/x20 Frequency Multiplier Switch
• 0-180 Degree Subwoofer Phase Switch
• Butterworth 12dB/Per Octave Slopes
• Detented Frequency Selection Controls
• Remote Level Knob Controller
• Bass boost
Specifications
| Signal-To-Noise Ratio | >97dB |
| Total Harmonic Distortion (1KHz, 1V RMS) | 0.02% |
| Crossover Slopes | 12dB/Per Octave Butterworth |
| Crossover Frequencies Front HighPassx1 Front HighPassx20 Rear HighPass Subwoofer |
32Hz to 600Hz 640Hz to 12KHz 32Hz to 600Hz 32Hz to 400Hz |
| Remote Sub Level | +18dB Boost |
| Low Level Input Voltage | 2V RMS |
| Maximum Output (10K Ohm Load) | 9V RMS |
| Supply Voltage | 9-15V |
| Dimensions | 145(L)x142(W)x33.5(H) mm |
