Comando Audio

CRX4-3600@1 | 3600W MAX | 4CH | 1Ω

CRX4-3600@1 | 3600W MAX | 4CH | 1Ω

Regular price
Regular price Sale price
Sale Coming soon

The new 2023 CRX amp series, features improved components, allowing the amp to tolerate 1 ohm loads. In addition, it features a bass boost function to push the lower frequencies. With improved power, better sound quality, and lower ohm load, the new 2023 CRX series will take your sound system to the next level.


The COMANDO/CRX amplifiers offer high quality audio reproduction for the audiophile and the everyday listener alike. All models feature fully variable crossovers with 12 dB per octave slopes, allowing you the ability to tailor the sound to best fit the speakers and your listening preferences.

PLATINUM FINISH CONNECTIONS Ensures solid electrical connections that resist corrosion.

FULLY VARIABLE CROSSOVERS Fully variable crossovers promote installation ease and save the cost of outboard crossovers. Additionally, they may be used in conjunction with outboard passive or active crossovers, depending on the complexity required by the system. The 12 Db per octave slope offers steep roll-off above or below the selected frequency.

PROTECTION CIRCUITRY Against overload, short circuit, thermal, low voltage, high voltage and reverse polarity. These protection features are designed to protect the amplifier from misuse, as well as from common causes of amplifier failure.

Features

• IRS(International Rectifier) Class-D Topology
• Crossover with bast booter function
• Mini Size footprint for easy installation of many applications
• Surface mount component technology
• Audio precision quality control verification
• Stable and reliable four layers PCB trace layout
• Power, protection, and clipping LED lights status indicator
• Short circuit, thermal, and voltage protection

Technical Data

RMS power output at 1Ω

900 watts

RMS power output at 2Ω

450 watts

RMS power output at 4Ω

225 watts

RMS power output at 2Ω bridge

1800 watts

RMS power output at 4Ω bridge

900 watts

Total harmonic distortion

<0.1%

S/N Ratio Ref 1W at 4Ω

>92 dB

Gain Range

0.2-6V

Crossover Range

40-4KHz

Frequency Range

20-20KHz

Bass Knob Controller

NO

Dimensions (mm)

197x117x45
